PILOT GIG TRAILER
GT900
The GT900 Cornish Pilot Gig Trailer is designed by a gig rower for gig rowers, and manufactured in Cornwall at the heart of Gig Boat racing.
“Robust and reliable”
Quality design and construction designed to protect your club’s most valuable asset.
- Fully IVA tested and approved.
- 4 fixed keel rollers, 4 height adjustable, and 2 adjustable front bow blocks.
- Full LED lighting with side markers & sealed electrics.
- Integrated lifting eyes
- Wide road tyres and front jockey wheel for easy movement on sand.
- Side supports which don’t drag the ground when lowered!
Designed specifically for towing Cornish Pilot Gig Boats
The GT900 Pilot Gig Boat Trailer is robust and reliable and designed from a user’s perspective. The single-piece main frame is fabricated and fully welded in steel, and then hot-dipped galvanised as one complete piece for the ultimate structural integrity and corrosion resistance.
Easy to use
Available as standard in a single axle configuration, for ease of movement when unhitched, this comes with 195/55 R13 wheels for easy travel across beaches when launching, and also for smooth towing along roads. The Jockey wheel fitted is puncture-proof and extra-wide, again for easy launching and movement. Mudguards are integrated into the frame of the machine from 2mm galvanised steel, and fully enclose the inside wheel arch to reduce mud and water spraying onto the boat.
The one-piece construction is designed to significantly reduce trailer flex, both laden and unladen, which reduces the potential for boat damage, as well as improving stability when towing. The bow of the boat is aligned right over the drawbar to reduce the towing length and improve balance, reducing bouncing.
4 fixed keel supports along the centre of the boat and 4 variable height supports to ensure the boat is well supported during transit. Side supports are angled and located such that when in the loading position (supports down) the keel supports do not drag the ground and are protected within the framework of the trailer itself.
Specification
| Fully IVA tested and approved |
| 4 fixed keel rollers, 4 height adjustable, and 2 adjustable front bow blocks |
| Full LED lighting with side markers & sealed electrics |
| Integrated lifting eyes |
| Wide road tyres and front jockey wheel for easy movement on sand |
| Side supports which don’t drag the ground when lowered! |
| Weight: 578kg |
Literature
Dimensions
